Programma SVERKER 750/760
Relay Test Set
- High current/high power output
- Freeze and hold readings
- Interconnect up to three test sets for three phase relays
- Read external volts and current
- 0 to 360 degrees phase shift capability
- Optional software automates testing
The SVERKER 750/760 Relay Test Unit is the engineer's toolbox. The control panel features a logical layout, still SVERKER 750/760 users will find it comfortably familiar and will be able to start work right away.
The SVERKER 750/760 features many functions that make relay testing more efficient and is designed to comply with OSHA and EU safety standards.
The SVERKER 750/760 features many functions that make relay testing more efficient. For example, its powerful measurement
ection can display voltage, current, time, impedance, resistance, reactance, apparent power, active power, reactive power, phase angle and power factor. The voltmeter can also be used as a second ammeter (when testing differential relays for example). All values are presented on a single easy-to-read display.
The SVERKER 760 has a continuous phase shift function enabling you to test directional relays. Automatic reclosing devices can also be tested just as easily.
The SVERKER 750/760 is designed to comply with OSHA and EU safety standards. SVERKER 750/760 is also equipped with a serial port for communication with personal computers and the PC software SVERKER Win. Since the compact SVERKER weights only 18 kg (39 lbs), it is easy to move from site to site.
The SVERKER 750/760 is capable of testing most single and polyphase protection relays including overcurrent, directional, undercurrent, differential and many others.
Programma SVERKER 650
Relay Test Set
- Designed for rugged field use
- 0 to 100 Amp output current
- Suitable for testing many different types of relays such as power, voltage and current
- Easy to operate
The Sverker 650 testing unit, whose design incorporates benefits gleaned from many years of experience in field relay testing, enjoys a well-earned reputation for reliability and convenience. Compact and powerful, it provides all of the functions needed for secondary testing of almost all types of single-phase protection now available on the market.
SVERKER 650 features logical design and construction, and it is extraordinarily easy to learn and use. Its compact design and light weight makes it extremely portable.
Auxiliary equipment for SVERKER 650 includes a test lead set and a rugged transport case. Another useful accessory is the
ACA120 voltage source which makes it easier to test directional relays.
Back To Top
Specifications
Specifications are valid at nominal input voltage and an ambient temperature of +25°C, (77°F). Specifications are subject to change without notice.
|
SVERKER 650 |
SVERER 750/760 |
| Environment |
| Application field |
The instrument is intended for use in high-voltage substations and industrial
environments. |
| Operating Temperature |
0°C to +50°C (32°F to +122°F) |
| Storage & transport |
-40°C to 70°C (-40°F to +158°F) |
| Humidity |
5% – 95% RH, non-condensing |
| CE-marking |
|
|
| LVD |
2006/95/EC |
Low Voltage Directive 73/23/ EEC am. by 93/68/EEC |
| EMC |
2004/108/EC |
EMC Directive 89/336/EEC am. by 91/263/EEC, 92/31/EEC and 93/68/EEC |
| General |
| Mains voltage |
115/230 V AC, 50/60 Hz |
| Power consumption (max) |
1100 VA |
1380 W |
| Protection |
Thermal cut-outs, miniature circuit breakers |
Thermal cut-outs, automatic overload protection |
| Dimensions |
| Instrument |
280 x 178 x 250 mm
(11" x 7" x 9.8") |
350 x 270 x 220 mm
(13.8" x 10.6" x 8.7") |
| Transport case |
560 x 260 x 360 mm
(22" x 10.2" x 14.2") |
610 x 350 x 275 mm
(24.0" x 13.8" x 10.8") |
| Weight |
16 kg (35.3 lbs)
26 kg (57.3 lbs) with accessories and transport case. |
| SVERKER 750 |
17.3 kg (38.1 lbs)26.3 kg (58 lbs)
with accessories and transport case |
| SVERKER 760 |
17.9 kg (39.5 lbs)26.9 kg (59.3 lbs)
with accessories and transport case |
|
Test lead set, with
4 mm stackable
safety plugs |
2 x 0.25 m (0.8 ft), 2.5 mm2
2 x 0.5 m (1.6 ft), 2.5 mm2
8 x 2.0 m (6.6 ft), 2.5 mm2 |
| Test leads with spade-tonge connectors |
2 x 3.0 m (9.8 ft), 10 mm2 |
